Description
Product brief:
Thermal gas flow meter is an instrument which measures fluid flow by means of heat conduction.
This gas flow meter be adopted constant temperature differential method to measure the gas mass flow , featured by small volume, high degree of digitization, convenient installation and accurate measurement
Flow sensor is made up of two platinum resistance temperature sensors. One sensor is applied in measuring fluid temperature, the other sensor to maintain the constant temperature differential
Product feature:
Easy installation, simple maintenance, two-way detection, anti-vibration
Flow measurement up to 24 points
Correction of output analog quantity Multi point nonlinear curve correction
Flow and temperature detection at the same time, switch display
Large diameter and small flow measurement, can be used for leak detection
Using proprietary technology “double balanced structure” package sensor
Proprietary high humidity and high temperature algorithm, the medium temperature can reach 500℃
4 lines LCD display Mass flow, Volume flow in standard condition, Flow totalizer, Date and Time, Working time, and Velocity, etc.
Due to the absence of moving parts, maintenance requirements are minimal. Volume flow and mass flow of gases can be measured without the need for pressure or temperature correction. All these features and capabilities add up to a thermal low flow measurement meter that cannot be surpassed for accuracy and ease of use.
Application:
As a true mass flow meter which could measure the gas flow conveniently and accurately without compensation for temperature or pressure. Mass flow or standard volume flow of the gas is to be obtained
Thermal gas flow meter widely for Machine manufacturing ,Electronic, Metallurgical, Power industry, Pulp industry
Mainly gas: Air, Natural gas, LPG gas, Biogas, Blast furnace gas, Coke oven gas, Steel Oxygen, Nitrogen.
Choose mode:
1. Fluid and fluid temperature
2. Display:Volume flow,Mass flow
3. Output:4-20mA,Pulse,RS485
4. Installation structure:Integral,Remote
5. Connection structure:Insert type,Inline type
6. Body material:SS304,SS316 optional
7. Pipe size:10~2000mm
Working pressure:1.6Mpa，2.5Mpa，4.0Mp
How to choose installation place:
When installing the thermal mass flow meter, keep away from elbows, obstacles, reducers and valves to ensure a stable flow field. It is required to have a long upper straight pipe. The front straight pipe length is greater than 10D, and the rear straight pipe length is greater than 5D.
